Compression load cells
Compression load cells are primarily intended for weighing heavy loads. They are particularly suitable for vehicle weighing or weighing tanks and silos.
Over twenty years of experience as a supplier of the largest manufacturers of weighbridges has enabled us to build a range of products recognised for their reliability. With tens of thousands of pieces installed, our compression load cells are a worldwide benchmark. With a weighing capacity of up to 1000 tonnes, Scaime's sensors and mounting kits offer reliability and safety in the most demanding applications.
![R10X R10X](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/R10X-1.jpg)
![r10x certs r10x certs](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/r10x-certs-1.jpg)
Stainless steel compression load cell
R10X
250 kg ... 100 t
- Load cell made of stainless steel, hermetically welded IP68
- Accuracy up to 0.05%
- Weight sensor including spherical load button for perfect load alignment
- Very easy to clean, for use in the food industry
- Load cell ideally suited for tanks and silos weighing or level measurement
- Available in High temperature version
- Optional connector output
- Capacities : 250 kg, 500 kg, 1 t, 2.5, 5, 10, 15, 30, 50, 100 t
![scaime logo-small scaime logo-small](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/scaime-logo-small.jpg)
![r10x-apps r10x-apps](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/r10x-apps.jpg)
![RH10X RH10X](https://www.positiveweighing.co.uk/wp-content/uploads/2019/06/RH10X.jpg)
![r10x certs r10x certs](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/r10x-certs-1.jpg)
Stainless steel high capacity compression load cell
RH10X
100 t ... 1000 t
- Load cell made of stainless steel, hermetically welded IP68
- Sensor accuracy up to ±0.2 %
- Spherical load button for perfect load alignment
- Load cell ideally suited for tanks or silos weighing and level measurement
- Capacities : 100, 200, 300, 500, 750, 1000t
- Higher capacities are available on request
![scaime logo-small scaime logo-small](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/scaime-logo-small.jpg)
![r10x-apps r10x-apps](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/r10x-apps.jpg)
![CB50X CB50X](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/CB50X.jpg)
![cb50x-certs cb50x-certs](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/cb50x-certs.jpg)
Stainless steel compression load cell
CB50X
5 t ... 60 t
- Column load cell made of stainless steel hermetically welded IP68
- Approved up to 4 000 d OIML R60 for use in legal for trade weighing applications
- Spherical and self-centering base
- Anti-rotation device included
- Load cell ideally suited for weighbridges construction and tank / silo weighing
- Matched sensor output signal for easy use in multi-cell applications
- Optional lightning protection
- Capacities : 5, 10, 20, 30, 40, 60 t
![scaime logo-small scaime logo-small](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/scaime-logo-small.jpg)
![cb50x apps cb50x apps](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/cb50x-apps.jpg)
![CB50X-DL CB50X-DL](https://www.positiveweighing.co.uk/wp-content/uploads/2019/06/CB50X-DL.jpg)
![cb50x-dl-certs cb50x-dl-certs](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/cb50x-dl-certs.jpg)
Stainless steel digital compression load cell
CB50X-DL
20 t ... 60 t
- Digital load cell made of stainless steel, hermetically welded IP68
- Approved 4 000 d OIML R60 for use in legal for trade weighing applications
- Digital RS485 sensor output
- Integrated DES protection
- Spherical and self-centering sensor base
- Load cell ideally suited for digital weighbridges construction
- Capacities : 20, 30, 40, 60 t
![scaime logo-small scaime logo-small](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/scaime-logo-small.jpg)
![cb50x apps cb50x apps](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/cb50x-apps.jpg)
![CA40X200t CA40X200t](https://www.positiveweighing.co.uk/wp-content/uploads/2019/06/CA40X200t.jpg)
![cb50x-certs cb50x-certs](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/cb50x-certs.jpg)
Stainless steel compression load cell
CA40X
100 t ... 200 t
- Load cell made of stainless steel hermetically welded IP68
- Sensor including spherical and self-centering base
- Anti-rotation device included
- Load cell ideally suited for silos weighing
- Capacities : 100, 200 t
![scaime logo-small scaime logo-small](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/scaime-logo-small.jpg)
![r10x-apps r10x-apps](https://www.positiveweighing.co.uk/wp-content/uploads/2020/11/r10x-apps.jpg)
