Digital load cells for weighbridges and packaging machines
We have combined our know-how in analogue signal processing with the latest digital technologies to offer a range of very high performance balances.
Thanks to several partnerships with world-class manufacturers of weighbridges and producers of packaging machines, SCAIME has acquired unique expertise in the integration of digital electronics in load cells.
Our offer includes digital compression sensors for weighbridges and single point digital load cells for packaging machines: Dosing machines, filling machines, portioning machines, grading machines and weight-sorting machines.
Stainless steel digital load cell - Dosing - 15 kg ... 75 kg
DVX-D
15 kg ... 75 kg
- Digital load cell dedicated to high speed weighing process control
- Load cell made of stainless steel, hermetically sealed IP69K
- Max. scale Platform size up to 400 x 400 mm
- Weighing capacities 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, filling, dosing by unloading
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
Stainless steel digital load cell - Checkweigher - 15 kg ... 75 kg
DVX-C
15 kg ... 75 kg
- Digital load cell dedicated to high speed weighing process control
- Load cell made of stainless steel, hermetically sealed IP69K
- Max. scale Platform size up to 400 x 400 mm
- Weighing capacities 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, Dynamic checkweighing
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
Digital and hygienic load cell - Dosing, 15 kg ... 75 kg
DVS-D
15 kg ... 75 kg
- Digital load cell with aseptic design, EHEDG certified
- Dedicated to high speed filling process control
- Load cell made of stainless steel, hermetically sealed IP69K
- Max. scale Platform size up to 400 x 400 mm
- Weighing capacities 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, filling, dosing by unloading
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
Digital and hygienic single point load cell - Checkweigher version
DVS-C
15 kg ... 75 kg
- Digital load cell with aseptic design, EHEDG certified
- Dedicated to high speed checkweighing
- Load cell made of stainless steel, hermetically sealed IP69K
- Max. scale Platform size up to 400 x 400 mm
- Weighing capacities 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, dynamic checkweighing
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
Digital single point load cell - Checkweigher, 5 kg ... 75 kg
AAD-D
5 kg ... 75 kg
- Digital load cell dedicated to high speed checkweighing
- Load cell made of aliminum, IP65 protection level
- Max. scale Platform size up to 600 x 400 mm
- Weighing capacities 5, 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, dynamic checkeweigher, sorting / grading functions
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
Digital single point load cell - Checkweigher, 5 kg ... 75 kg
AAD-C
5 kg ... 75 kg
- Digital load cell dedicated to high speed checkweighing
- Load cell made of aliminum, IP65 protection level
- Max. scale Platform size up to 600 x 400 mm
- Weighing capacities 5, 15, 30, 75 kg
- Resolution up to 500 000 pts
- Part certificate of NAWI (OIML R76) and AWI (OIML R51 and R61)
- Integrated weighing functions: High speed transmitter, dynamic checkeweigher, sorting / grading functions
- Programmable digital filters
- 2 digital inputs and 4 digital outputs
- 1 RS485 output and 1 CANbus output
- MODBUS-RTU and CANOpen® protocols
